This model features Multiple lavs 0.2 which turn on with 110° temp setting.Applications

• Lavatory sinks
• Multi lav configurations ideal for sensor or metering faucets (ML option - 110 F max.)
• Emergency eye wash fountains (EE option - 90 F max.)Features
  • Lowest activation in industry with 0.2 GPM turn on flow
  • Active energy management with power modulating controls
  • Microprocessor temperature control with digital display for thermostatic accuracy
  • Field adjustable set point range between 70-140 F. Factory set at 120 F (3.5kW and below set at 105 F).
  • Special settings of higher or lower range available based on options
  • Silent Operation (except for SPEX0122240T)
  • Mounts in any orientation
  • Flow meter activates heater only on demand (no standby heat loss)
  • Install unit at point-of-use to eliminate long pipe runs
  • Eliminate costly mixing valve
  • Compact size fits almost anywhere for flexible installation; suitable for ADA compliant facilities
  • Cover Material: ABS-UL 94 5VA
  • Element Type: Replaceable cartridge - bare wire
  • Element Material: Ni Chrome

  Specifications:

  • Kilowatts (KW): 6.5
  • Energy Factor: 0.99
  • Efficiency: 99%
  • Voltage: 240v
  • Amperage: 27
  • Max Operating Pressure: 140 PSI
  • Min Operating Pressure (PSI): 30
  • Max Pressure (PSI): 150
  • Min Flow (GPM): 0.5
  • Max Flow (GPM): 2.0
  • Fuel Type: Electric
